Rust API Bindings: Core Foundation Signed/Unsigned Conversion

Brian T. Kelley Dec 27, 2023 8 min read

Small green and blue images swirling around in a vortex. The scene is somehow both chaotic and orderly.

Handling CFIndex/usize (signed/unsigned) conversion is important in crafting idiomatic Rust API bindings. I looked at how Apple handled this conversion between Core Foundation and Foundation, and between Foundation and Swift to help inform the direction for my Core Foundation crate.

Core Foundation’s canonical index type and size type, CFIndex, is signed. Foundation’s canonical index type and size type, NSUInteger, is unsigned, and Rust’s canonical type, usize, is unsigned too.

Handling CFIndex/usize (signed/unsigned) conversion is important in crafting idiomatic Rust API bindings. Before implementing an approach for my crate, I looked at how Apple handled this problem for Core Foundation↔Foundation and Foundation↔Swift to understand how they balanced performance (an unchecked bit cast) with correctness (detect and handle a sign change).

Toll-Free Bridging Approach

Many Core Foundation and Foundation types are interchangeable. CFIndex is used throughout Core Foundation, while Foundation’s equivalent interface uses NSUInteger. I don’t have access to the Foundation source code, but in peeking at the assembly (examples below), it seems Foundation effectively uses an unchecked bit cast when converting between CFIndex and NSUInteger—the values pass through without detection of a potential sign change. So, integer values with the bit at 1 << sizeof(size_t) * 8 - 1 set to 1 will be negative in the Core Foundation interface but positive in the Foundation interface.

The only acknowledgment of the type mismatch in Apple’s documentation (as far as I’m aware) is this (slightly edited) description of the location and length fields on CFRange and NSRange:

For type compatibility with the rest of the system, LONG_MAX is the maximum value you should use for location and length.

An interesting related quirk is the difference between kCFNotFound and NSNotFound. Although many Core Foundation and Foundation types are interchangeable, the semantic "not found" value is interface-dependent. kCFNotFound is defined as -1 while NSNotFound is NSIntegerMax (i.e., the maximum value of CFIndex, LONG_MAX). So, the addressable range of failable Foundation methods returning an NSRange is effectively limited to [0, LONG_MAX).

Using a signed type in the underlying Core Foundation implementation and NSNotFound's definition as the maximum signed value inhibit Foundation from utilizing the full range of the unsigned type.

Unchecked Bit Cast Examples

-[NSString length] returns an NSUInteger, but its implementation is a simple tail call into Core Foundation’s _CFStringGetLength2, which returns a CFIndex.

CoreFoundation`-[__NSCFString length]:
  b       _CFStringGetLength2

Every method in Objective-C has two implicit arguments:

self: The pointer to the object instance
_cmd: The SEL that resolved to the method

The above tail call works because _CFStringGetLength2 has one argument, the pointer to the object instance, so the Objective-C method and the Core Foundation C function have the same ABI, and no work is required to forward the arguments. (_CFStringGetLength2 ignores the second argument.)

-[NSString getCharacters:range:], on the other hand, has to do some work before and after its call to Core Foundation’s _CFStringCheckAndGetCharacters:

The Objective-C method has four arguments (self, _cmd, buffer, and range), while the Core Foundation function has three (str, range, buffer). Removing _cmd requires moving the arguments that follow it. Also, in this case, the last two arguments are swapped between the interfaces and need to be reordered.
Generally, Core Foundation does not do bounds checking, while Foundation does. Foundation calls a Core Foundation SPI (System Programming Interface) that returns an error code if the range is out of bounds so Foundation can raise an exception.

CoreFoundation`-[__NSCFString getCharacters:range:]:
  pacibsp                         ; insert PAC into LR using SP as the modifier and key B
  stp     x20, x19, [sp, #-0x20]! ; SP -= 0x20; SP[0x00] = x20; SP[0x08] = x19
  stp     x29, x30, [sp, #0x10]   ; SP[0x10] = FP; SP[0x18] = LR;
  add     x29, sp, #0x10          ; FP = SP + 0x10 (address of {FP, LR})
  mov     x8, x2                  ; x8 = buffer (temporary)
  mov     x19, x1                 ; x19 = _cmd
  mov     x20, x0                 ; x20 = self
  mov     x1, x3                  ; x1 = range.location (arg 1, part 1/2)
  mov     x2, x4                  ; x2 = range.length   (arg 1, part 2/2)
  mov     x3, x8                  ; x3 = buffer         (arg 2)
  bl      _CFStringCheckAndGetCharacters
  cbnz    w0, raiseException      ; goto raiseException if _CFStringCheckAndGetCharacters did not return 0
  ldp     x29, x30, [sp, #0x10]   ; FP = SP[0x10]; LR = SP[0x18]
  ldp     x20, x19, [sp], #0x20   ; x20 = SP[0x00]; x19 = SP[0x08]; SP += 0x20
  retab                           ; return using PAC with SP as the modifier and key B
raiseException:
  mov     x0, x20                 ; x0 = self
  mov     x1, x19                 ; x1 = _cmd
  bl      -[__NSCFString getCharacters:range:].cold.1

Although some code is required to adapt the Foundation interface to Core Foundation, there is no validation of the range’s unsigned to signed conversion.

Swift’s Approach

For Apple’s frameworks (e.g., AppKit, Foundation, UIKit, etc.), the Swift compiler imports NSUInteger as Int. To make C and Objective-C interfaces visible to Swift code, the Swift compiler "imports" a Clang module to build a Swift module, where "import" is a Swift compiler process that constructs a Swift-native representation of the compatible declarations, definitions, and types present in the Clang module.

Normally, NSUInteger imports as UInt. But, in system modules (i.e., modules found under a directory given by an -isystem flag), Swift silently retypes NSUInteger to Int unless the NSUInteger declares the type of an enum. This retyping operation occurs during the construction of the Swift module. The compiler does not record any metadata about this change, and the operation is not visible to other parts of the compiler. Therefore, any thunks emitted by the compiler to facilitate crossing the language boundary do not check for a potential sign change.

Down the Rabbit Hole

I looked at the Swift compiler implementation to see under what conditions the change from unsigned to signed took place and how it was implemented.

Swift’s ClangImporter's shouldAllowNSUIntegerAsInt member function contains the main logic to determine if the compiler should change the type of NSUInteger to Int. It returns true if:
- The declaration is from a system module.
- And the declaration’s name does not contain Unsigned or unsigned, which is a special case to preserve NSUInteger for +[NSNumber numberWithUnsignedInteger:], -[NSNumber initWithUnsignedInteger:], and -[NSNumber unsignedIntegerValue].
There are two ways to identify a Clang module as a system module:
- Its module map has the [system] attribute.
- The compiler loaded the module map from a system directory.
  1. In this case, the loading of the module map occurs when resolving header search paths.
  2. The module inherits the IsSystem flag from the directory containing its module map.
  3. Any directory that’s not a user directory is a system directory.
  4. Clang identifies non-user directories as those belonging to one of its system directory groups.
  5. The compiler invocation arguments identify which directories belong to the system directory groups.

My Crate’s Approach

In considering various signed/unsigned conversion approaches for my Core Foundation Rust API bindings, I evaluated Foundation’s and Swift’s approach (transparent retyping) with Rust’s behavior considered undefined. Although Foundation’s and Swift’s approaches may lead to an unexpected sign change, they are not considered unsafe by Rust’s definition. The only potentially related undefined behavior is "Calling a function with the wrong call ABI," but signed-ness is not generally considered part of the C ABI.

I introduced two traits to facilitate signed/unsigned conversion:

ExpectFrom performs the signed/unsigned conversion and panics if the conversion fails. Implementations are a convenience wrapper for <T as TryFrom>::try_from(value).expect(""), which, while trivial, reduces the number of ad hoc expects in bindings code to improve readability. This trait primarily facilitates conversions from idiomatic Rust types into native Core Foundation types. It provides a user-visible signal if CFIndex cannot represent an index or size.
FromUnchecked performs the signed/unsigned conversion and assumes the result is correct, emulating the transparent retyping approach of Foundation and Swift. This trait primarily facilitates conversions from native Core Foundation types into idiomatic Rust types where it’s reasonable to assume the value is in bounds.

If a sign change goes undetected, safe Rust code will panic. Unsafe code must ensure all values are in bounds for the given domain so an undetected sign change does not impose any additional burden, assuming a sign change would cause the value to go out of bounds.
